Rugged Gigabit PoE++ Extender
Rugged Gigabit PoE++ Extender
IEEE 802.3bt (4PPoE) Compliant, One PD Port up to 65 W, Extends PoE from 100 m (328 ft.) to 200 m (656 ft), Daisy-Chainable up to Five Units, IP30-Rated Aluminum Housing, Wall-Mountable
SKU: 562331 IPE-INDG65
In stock
Request access to B2B pricing here.
Couldn't load pickup availability
Highlights
- Doubles the maximum connection distance between PoE source and device from 100 m (328 ft.) to 200 m (656 ft.)
- Delivers up to 65 W to a connected PoE device
- Rugged IP30-rated aluminum housing to withstand harsh industrial conditions
PoE++ Extender Repeater - double the range of your Gigabit Power over Ethernet connection, even in harsh conditions
The Intellinet Network Solutions Rugged Gigabit PoE++ Extender adds up to 100 m (328 ft.) to the connection distance from a PoE source to one output device via network patch cable. This PoE++ (4PPoE) extender does not need an additional power supply since it draws its power from the PoE input.
Rugged Aluminum housing
This Power over Ethernet extender was designed to give you the network connections you need in places that are less than calm or temperate. With its rugged, IP30-rated aluminum housing, it operates reliably and quietly, which makes it even suitable for indoor industrial applications in Industry 4.0 and more.
Reduced Wiring Costs
It helps avoid the expense of running AC power lines for a wireless access point, network camera, IP phone, or other compatible device. Simply connect the PoE Extender to the LAN switch port through existing Cat5e/6/6a cables to deliver power as well as transfer data.
Power over Ethernet 802.3bt Compliant
The 4PPoE Extender supports the IEEE 802.3bt protocol over four pairs (4PPoE), which allows for a power input of 95 W. It forwards data at Gigabit speeds and offers up to 65 watts to a connected, IEEE 802.3bt-, IEEE 802.3at- or IEEE 802.3af-compliant device. The cable length on both ends can be up to 100 m (328 ft.), bringing the total distance between PoE source and device to 200 m (656 ft.).
Simple Installation
This PoE Extender was designed to be as easy as possible to set up and use. All it takes to have it up and running is to connect its PoE In port to your PoE injector or PoE switch and to connect the PoE Out ports to the PoE devices you want to connect (e.g., a VoIP phone and a PoE network camera).
Cascading Power
For larger deployments, up to five extenders can be daisy-chained to achieve a total PoE distance of up to 600 meters (1968 ft.). This makes it ideal for network cameras, wireless access points, VoIP phones, and other IEEE 802.3bt/at/af-compliant devices in warehouses, factories, campuses, or commercial buildings.
