Power Extension Cord C13 to C14, 6 ft.

C13 to C14 PDU Power Cable / 6 ft. Extension Cord for Network Equipment and More

Meet the power management demands in IT and network environments with the heavy-duty Power Extension Cord (6 ft.) from Intellinet Network Solutions. Whether you're managing a data center, optimizing an office setup, or need reliable power for your workstation, this extension cord is the smart choice for dependable performance. The 14 AWG wire is suitable for high power connections, ideal for large server applications that require a higher rated, heavier gauge cable, as well as for connecting to Power Distribution Units (PDU). With a C14 connector on one end and a C13 connector on the other, it can extend the power cable length for most network devices.

Versatile Connectivity

Perfect for connecting devices like servers, computers, monitors, and printers to PDUs, UPS systems, surge protectors or other compatible power supplies, this cable is ideal for rackmount network applications, ensuring your equipment stays powered and operational.

Extended Reach

Need a bit more length? Easily extend your existing C13 to AC power cables to reach wall outlets or distant power sources, providing the flexibility you need in any setup.

Safety Certified and Flame Retardant

UL listed for safety and reliability, this cable gives you peace of mind that your equipment is in good hands. It boasts a flame-retardant rating in accordance with VW-1 standards, ensuring enhanced safety in case of fire hazards.

High Quality backed up by a Lifetime Warranty

Its high-temperature resistance up to 221°F (105°C) makes it ideal for use in environments that may not be air-conditioned or that experience high heat. The cord features a flexible, durable SJT jacket with heavy-duty strain relief, designed to withstand the rigors of frequent use and handling. Made with pure bare copper wire for maximum conductivity and efficient power transmission, ensuring your devices receive a stable power supply.

Perfect Pairing with our PDUs

Ideal for use with our C13 PDUs like the Intellinet 19" Rackmount Smart Switched Metered 8-Outlet PDU (#163682), it provides an optimized power solution for your network needs.

• Connects devices like server, computer, monitor and printer to a PDU, UPS or other power supply, great for rackmount network applications
• Extends a C13 to AC power cable for an enhanced reach to a wall outlet
• UL listed
• Flame retardant rating in accordance with VW-1
• Flexible, durable SJT jacket with heavy-duty strain relief
• Pure bare copper wire for maximum conductivity
• For indoor use, rated to carry 125 V at 15 A
• Ideal for use with Intellinet 19" Rackmount Smart Switched Metered 8-Outlet PDU (#163682)
• Lifetime warranty

Standards and Certifications

• UL

• cUL

• RoHS

• REACH

• IEC 60320

  General:

• Connector 1: IEC 320 C14 plug (male)

• Connector 2: IEC 320 C13 socket (female)

• Maximum current: 15.0 A

• Maximum voltage: 125.0 V AC

• Rated voltage: 300.0 V

• Flame resistance rating: VW-1

  Physical

• Wire: 100% pure bare copper (Cu)

• Jacket and boot material: SJT

• Wire gauge: 14 AWG (2.08 mm²)

• Number of cores: 3

• Number of strands / strand thickness: 66 / 0.008 in. (0.2 mm)

• Nominal overall diameter: 0.36 to 0.39 in. (9.14 to 10 mm)

• Length: 6 ft.(1.8 m)

• Net weight: 0.64 lbs (290 g)

• Gross weight: 0.66 lbs.(300 g)

  Environmental

• Operation temperature: -4 - 140°F (-20 - 60°C)

• Operating humidity (non-condensing): 10 - 65%

  Package Contents

• Power Extension Cord C13 to C14, 3 ft.

• Additional SKUs

• EAN: 0766623356480
• UPC: 766623356480



• Physical Specifications

• Product net weight: 0.29 kg
• Product gross weight: 0.3 kg
• Dimensions: 1.8 (L) x 0.025 (W) x 0.015 (H) [m]
• Packaging: Bag

• Datasheet
• Datasheet     » Download
