Gigabit PCI Express Network Card
Gigabit PCI Express Network Card
10/100/1000 Mbps PCI Express Ethernet Card
In stock
Highlights
- Supports Gigabit speeds over existing network cable
- Does not require fiber optic cabling to run Gigabit speeds
- PCI Express 1.0a bus interface fits 1, 4, 8 and 16X PCI-E slots
[ view high resolution images ]
The Gigabit PCI Express Network Card is a high-performance network adapter. It supports the PCI Express bus architecture, which provides faster throughput than the current 32- and 64-bit PCI bus architectures. And there is no need to switch to fiber optic cable — the Intellinet Network Solutions Gigabit PCI Express Network Card allows you to run Gigabit speeds over your existing copper wire network cable.
Faster Throughput
The PCI Express host interface supports throughput rates of up to 2 Gbps when running in full duplex mode, ideal for resource-intensive CAD/CAM, client-server database, multimedia, pre-press, advertising graphics, server and mission-critical applications.
Auto-Negotiation
The Gigabit PCI Express Network Card will automatically detect the network speed that the LAN switch port is set to and run at the same speed. The card supports 10Base-T Ethernet, 100Base-TX Fast Ethernet and 1000Base-T Gigabit Ethernet.
Full Duplex
When running in full duplex mode, the Gigabit PCI Express Network Card provides the following throughput rates: 20 Mbps (10Base-T Ethernet), 200 Mbps (100Base-TX Fast Ethernet) and 2 Gbps (1000Base-T Gigabit Ethernet).
Built-In Diagnostics
The Gigabit PCI Express Network Card comes standard with crossover detection and auto correction capabilities that make installation and maintenance a snap.
Remote Power On
The Wake-On-LAN feature allows you to power on your desktop PC from anywhere on the network.
- Supports Gigabit speeds over existing network cable
- Does not require fiber optic cabling to run Gigabit speeds
- PCI Express 1.0a bus interface fits 1, 4, 8 and 16X PCI-E slots
- Single PCI Express lane (x1) 2.5 Gbps interface
- Full duplex flow control (IEEE 802.3x)
- Supports jumbo frames up to 9 kB
- Full duplex speeds (20 Mbps, 200 Mbps, 2000 Mbps)
- Includes low profile 8 cm bracket
- Wake-On-LAN (WOL) support
- Supports the most popular operating systems: Windows Vista/7/8/8.1/10/11 and Linux
- Three-Year Warranty
- Network
- IEEE 802.1p (Traffic Prioritization)
- IEEE 802.1q (VLAN Tagging)
- IEEE 802.3 (10Base-T Ethernet)
- IEEE 802.3u (100Base-TX Fast Ethernet)
- IEEE 802.3ab (1000Base-T Gigabit Ethernet)
Hardware - FCC & CE compliance
- Compliant with PCI-E 1.1 X1 Serial PCI Express
- Link LED
- Act LED
Environmental - Dimensions: 121 (L) x 68 (W) x 19 (D) mm (4.76 x 2.68 x 0.75 in.)
- Weight: 39.6 g (1.4 oz.)
- Operating temperature: 0 – 40°C (32 – 104°F)
- Storage temperature: 0 – 65°C (32 – 149°F)
- Operating humidity: 10 – 90%, non-condensing
- Storage humidity: 5 – 95%, non-condensing
Supported OS - Windows Vista/7/8/8.1/10/11
- Linux
Package Contents - Gigabit PCI Express Network Card
- Low-profile 8cm bracket
Additional SKUs
- Alphanumeric Part#: INC-1G-PCIE
- Amazon ASIN: B001P8V50U
- EAN: 0766623522533
- UPC: 766623522533
Physical Specifications
- Product net weight: 0.03 kg
- Product gross weight: 0.1 kg
- Dimensions: 121 (L) x 68 (W) x 19 (H) [mm]
- Packaging: Retail Box
Warning
This product can expose you to chemicals including Cadmium, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.gov.- Datasheet
- Datasheet » Download
- Driver
- Windows 2000/XP (32-bit)
Chipset: Marvell Yukon » Download - WIndows 2003 Server/XP (64-bit)
Chipset: Marvell Yukon » Download - Windows Vista & 2008 Server (32-bit)
Chipset: Marvell Yukon » Download - Complete Windows Driver
Win 2000/XP/2003/Vista/2008 x86 and x64 Multi-Language Installer (32- and 64-bit).
Chipset: Realtek
Date: 8/18/08 » Download - Windows 7
Chipset: Marvell Yukon » Download - Windows 8 Auto-Installation Program
For Realtek chipset only
1. Unzip the file
2. Run setup.exe » Download - Windows 2000, XP, Vista and Windows 7
Chipset: Realtek » Download - Windows 10 » Download
- Windows 8, Windows 8.1 and Server 2012 Auto Installation Program
For Realtek chipset only.
1. Unzip the file
2. Run setup.exe » Download - Windows 7 and Server 2008 R2 Auto Installation Program
For Realtek chipset only.
1. Unzip the file
2. Run setup.exe » Download - Windows Vista and Server 2008 Auto Installation Program
For Realtek chipset only.
1. Unzip the file
2. Run setup.exe » Download - Manual
- Utility
- Network Control Utility
Aggregation and VLANs in x86 & x64 XP, Server 2003, Vista, Server 2008 » Download
