10 m LC to LC UPC Fiber Optic Patch Cable, 3.0 mm, Duplex, LSZH, OS2 Singlemode, Yellow
10 m LC to LC UPC Fiber Optic Patch Cable, 3.0 mm, Duplex, LSZH, OS2 Singlemode, Yellow
9/125 µm, 33 ft.
SKU: 516815
In stock
Regular price
$11.99 USD
Regular price
Sale price
$11.99 USD
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
Buy at discounted prices
Qty | Discount | New unit price |
---|---|---|
5 | 5% off | $11.39 per unit |
10 | 10% off | $10.79 per unit |
20 | 15% off | $10.19 per unit |
50 | 20% off | $9.59 per unit |
Highlights
- UPC (Ultra Physical Contact) fiber connectors ensure superior surface finish and minimized return loss, enhancing overall performance.
- Compatible with single-mode fiber applications, providing versatility for various networking needs.
- High bandwidth capability supports extended distances, ensuring reliable connectivity across large networks.
- Low signal loss and high data rate transmission guarantee efficient data transfer without compromise.
- Perfect for 10G Ethernet applications and beyond, offering seamless integration and optimal performance for high-speed networks.
- Backed by a lifetime warranty, providing assurance of quality and reliability for long-term use.
![NDAA Compliant NDAA Compliant](https://cdn.shopify.com/s/files/1/0419/4903/6694/files/ndaa-icon-180-48.jpg?v=1718031684)
[ view high resolution images ]
Information carried in the form of light provides a vast array of features and benefits
Superior Transmission Distance
It is not unusual for optical systems to go over 100 kilometers (km), or about 62 miles.
Enhanced Security
It is impossible to remotely detect a signal being transmitted within a fiber cable. The only way to do so is by actually accessing the optical fiber itself. This makes fiber extremely attractive to governmental bodies, banks and other businesses with major security concerns.
No Metallic Components
Fiber optic cable can be installed in areas with electromagnetic interference (EMI). This includes areas around utility lines, power-carrying lines and railroad tracks. Fiber is also ideal for areas of high lightning-strike incidence.
- Compatible with single-mode fiber applications
- High bandwidth supporting long distances
- Low signal loss and high data rate
- Perfect for use in 10G Ethernet applications and beyond
- Lifetime Warranty
- Standards and Certifications
- Diameters:
- Core: 9 µm
- Cladding: 125 µm - Fiber type: single-mode
- Connectors: LC to LC
- Duplex
- Jacket material: LSZH
- Jacket OD: 3.0 mm
- Jacket color: yellow
- Ferrule Material: Ceramic
- Polishing: UPC
- Operation Temperature Range: -40°C to +75°C
- Bending radius: 30 mm
- Return loss: ≥55dB
- Insertion loss: ≤ 0.25 dB
Additional SKUs
- Amazon ASIN: B0072IIJS8
- EAN: 0766623516815
- UPC: 766623516815
Physical Specifications
- Product net weight: 0.13 kg
- Product gross weight: 0.15 kg
- Dimensions: 10 m
- Packaging: Bag
